Model & Selection
Dimensional Drawing
Model & Specification Comparison
| SKU | Motor Model | Motor Type | Rated Voltage | No Load Speed | Rated Speed | No Load Current | Rated Current | Stall Current | Rated Torque | Stall Torque | Rated Power | Max Efficiency | Motor Diameter | Motor Length | Motor Weight | Shaft Diameter | Shaft Configuration | Connector | Working Lifespan | Operating Temperature Range | Housing Material | Direction Of Rotation | Enameled Wire Material | Magnet Material | Carbon Brush Material | Insulation Class | Number Of Pole Pairs | Gearbox |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 55512300 | DC555-123000 | Brushed DC Motor | 12 V | 3,000 rpm | 2,600 rpm | 180 mA | 600 mA | 3,100 mA | 179 gf·cm | 1,650 gf·cm | 5 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
| 55512450 | DC555-124500 | Brushed DC Motor | 12 V | 4,500 rpm | 3,929 rpm | 280 mA | 840 mA | 5,920 mA | 183 gf·cm | 1,507 gf·cm | 7.42 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
| 55512600 | DC555-126000 | Brushed DC Motor | 12 V | 6,000 rpm | 5,244 rpm | 420 mA | 1,340 mA | 9,310 mA | 215 gf·cm | 1,722 gf·cm | 11.60 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
| 55524300 | DC555-243000 | Brushed DC Motor | 24 V | 3,000 rpm | 2,663 rpm | 100 mA | 240 mA | 1,930 mA | 158 gf·cm | 1,470 gf·cm | 4.11 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
| 55524450 | DC555-244500 | Brushed DC Motor | 24 V | 4,500 rpm | 3,980 rpm | 140 mA | 440 mA | 3,340 mA | 190 gf·cm | 1,713 gf·cm | 7.55 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
| 55524600 | DC555-246000 | Brushed DC Motor | 24 V | 6,000 rpm | 5,300 rpm | 250 mA | 730 mA | 5,450 mA | 244 gf·cm | 2,065 gf·cm | 12.90 W | 72 % | 36 mm | 57 mm | 230 g | 3.17 mm | Single/Dual | 2 | 600 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG36/SG37/TT/GF/TA |
Technical Specifications
| Motor Model | DC555-123000 |
|---|---|
| Motor Type | Brushed DC Motor |
| Rated Voltage | 12 V |
| No Load Speed | 3,000 rpm |
| Rated Speed | 2,600 rpm |
| No Load Current | 180 mA |
| Rated Current | 600 mA |
| Stall Current | 3,100 mA |
| Rated Torque | 179 gf·cm |
| Stall Torque | 1,650 gf·cm |
| Rated Power | 5 W |
| Max Efficiency | 72 % |
| Motor Diameter | 36 mm |
| Motor Length | 57 mm |
| Motor Weight | 230 g |
| Shaft Diameter | 3.17 mm |
| Shaft Configuration | Single/Dual |
| Connector | 2 |
| Working Lifespan | 600 hours |
| Operating Temperature Range | -30 ~ 65 C |
| Housing Material | Electrolytic zinc coated steel |
| Direction Of Rotation | CW/CCW |
| Enameled Wire Material | Enameled copper wire |
| Magnet Material | Ferrite |
| Carbon Brush Material | Metal graphite brush |
| Insulation Class | UEW |
| Number Of Pole Pairs | 2 |
| Gearbox | PG36/SG37/TT/GF/TA |
