Model & Selection
Model & Specification Comparison
Technical Specifications
| Product Model | SR37555123000- |
|---|---|
| Gearbox Weight | 338 g |
| Rated Voltage | 12 V |
| No Load Speed | 315.789474 rpm |
| Rated Speed | 274 rpm |
| No Load Current | 180 mA |
| Rated Current | 600 mA |
| Stall Current | 3,100 mA |
| Rated Torque | 1241 gf·cm |
| Stall Torque | 11442.75 gf·cm |
| Rated Power | 3.50 W |
| Max Efficiency | 52.560 % |
| Motor Diameter | 37 mm |
| Gearbox Length | 87.5 mm |
| Gear Ratio | 9.5 :1 |
| Number Of Gear Stages | 3 |
| Max Continuous Torque | 2 kgf·cm |
| Instantaneous Break Torque | 6 kgf·cm |
| Backlash | 2 ° |
| Operating Temperature Range | -30 ~ 65 C |
| Working Lifespan | 600 hours |
