Model & Selection
Dimensional Drawing
Model & Specification Comparison
| SKU | Motor Model | Motor Type | Rated Voltage | No Load Speed | Rated Speed | No Load Current | Rated Current | Stall Current | Rated Torque | Stall Torque | Rated Power | Max Efficiency | Motor Diameter | Motor Length | Motor Weight | Shaft Diameter | Shaft Configuration | Connector | Working Lifespan | Operating Temperature Range | Housing Material | Direction Of Rotation | Enameled Wire Material | Magnet Material | Carbon Brush Material | Insulation Class | Number Of Pole Pairs | Gearbox |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5012900 | DC050-129000 | Brushed DC Motor | 12 V | 9,000 rpm | 7,000 rpm | 45 mA | 140 mA | 500 mA | 8 gf·cm | 45 gf·cm | 0.50 W | 75 % | 15.5 mm | 26.9 mm | 16 g | 1.5 mm | Single/Dual | 2 | 150 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG16 |
| 5012120 | DC050-1212000 | Brushed DC Motor | 12 V | 12,000 rpm | 9,600 rpm | 55 mA | 180 mA | 750 mA | 10 gf·cm | 50 gf·cm | 0.90 W | 75 % | 15.5 mm | 26.9 mm | 16 g | 1.5 mm | Single/Dual | 2 | 150 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG16 |
| 5024130 | DC050-2413000 | Brushed DC Motor | 24 V | 13,000 rpm | 10,000 rpm | 45 mA | 110 mA | 400 mA | 12 gf·cm | 49 gf·cm | 1.20 W | 75 % | 15.5 mm | 26.9 mm | 16 g | 1.5 mm | Single/Dual | 2 | 150 hours | -30 ~ 65 C | Electrolytic zinc coated steel | CW/CCW | Enameled copper wire | Ferrite | Metal graphite brush | UEW | 2 | PG16 |
Technical Specifications
| Motor Model | DC050-129000 |
|---|---|
| Motor Type | Brushed DC Motor |
| Rated Voltage | 12 V |
| No Load Speed | 9,000 rpm |
| Rated Speed | 7,000 rpm |
| No Load Current | 45 mA |
| Rated Current | 140 mA |
| Stall Current | 500 mA |
| Rated Torque | 8 gf·cm |
| Stall Torque | 45 gf·cm |
| Rated Power | 0.50 W |
| Max Efficiency | 75 % |
| Motor Diameter | 15.5 mm |
| Motor Length | 26.9 mm |
| Motor Weight | 16 g |
| Shaft Diameter | 1.5 mm |
| Shaft Configuration | Single/Dual |
| Connector | 2 |
| Working Lifespan | 150 hours |
| Operating Temperature Range | -30 ~ 65 C |
| Housing Material | Electrolytic zinc coated steel |
| Direction Of Rotation | CW/CCW |
| Enameled Wire Material | Enameled copper wire |
| Magnet Material | Ferrite |
| Carbon Brush Material | Metal graphite brush |
| Insulation Class | UEW |
| Number Of Pole Pairs | 2 |
| Gearbox | PG16 |
