Technical Specifications
| Product Model | TA775123000- |
|---|---|
| Gearbox Weight | 767 g |
| Rated Voltage | 12 V |
| No Load Speed | 85.714286 rpm |
| Rated Speed | 70 rpm |
| No Load Current | 420 mA |
| Rated Current | 1,200 mA |
| Stall Current | 6,000 mA |
| Rated Torque | 9923 gf·cm |
| Stall Torque | 64,638 gf·cm |
| Rated Power | 7131.16 W |
| Max Efficiency | 58.320 % |
| Gearbox Length | 199 mm |
| Gear Ratio | 35 :1 |
| Number Of Gear Stages | 3 |
| Max Continuous Torque | 150 kgf·cm |
| Instantaneous Break Torque | 500 kgf·cm |
| Backlash | 3 ° |
| Operating Temperature Range | -30 ~ 65 C |
| Working Lifespan | 800 hours |
| Noise Level @ 30cm | 53 |
