Technical Specifications
| Product Model | RG50B775123000- |
|---|---|
| Gearbox Weight | 473 g |
| Rated Voltage | 12 V |
| No Load Speed | 400 rpm |
| Rated Speed | 327 rpm |
| No Load Current | 420 mA |
| Rated Current | 1,200 mA |
| Stall Current | 6,000 mA |
| Rated Torque | 2126 gf·cm |
| Stall Torque | 13,851 gf·cm |
| Rated Power | 7.16 W |
| Max Efficiency | 58.320 % |
| Motor Diameter | 50 mm |
| Gearbox Length | 92.4 mm |
| Gear Ratio | 7.5 :1 |
| Number Of Gear Stages | 2 |
| Max Continuous Torque | 10 kgf·cm |
| Instantaneous Break Torque | 30 kgf·cm |
| Backlash | 2 ° |
| Operating Temperature Range | -30 ~ 65 C |
| Working Lifespan | 800 hours |
| Noise Level @ 30cm | 53 |
