Model & Selection
Model & Specification Comparison
Technical Specifications
| Product Model | PG25370124500-4K |
|---|---|
| Gearbox Weight | 99 g |
| Rated Voltage | 12 V |
| No Load Speed | 1,125 rpm |
| Rated Speed | 975 rpm |
| No Load Current | 33 mA |
| Rated Current | 160 mA |
| Stall Current | 1,000 mA |
| Rated Torque | 108 gf·cm |
| Stall Torque | 576 gf·cm |
| Rated Power | 1.08 W |
| Max Efficiency | 67.500 % |
| Motor Diameter | 25 mm |
| Gearbox Length | 55.8 mm |
| Gear Ratio | 4 :1 |
| Number Of Gear Stages | 1 |
| Max Continuous Torque | 3 kgf·cm |
| Instantaneous Break Torque | 9 kgf·cm |
| Operating Temperature Range | -30 ~ 65 C |
| Working Lifespan | 300 hours |
