Model & Selection
Model & Specification Comparison
Technical Specifications
| Product Model | MG775123000- |
|---|---|
| Gearbox Weight | 611 g |
| Rated Voltage | 12 V |
| No Load Speed | 230.769231 rpm |
| Rated Speed | 188 rpm |
| No Load Current | 420 mA |
| Rated Current | 1,200 mA |
| Stall Current | 6,000 mA |
| Rated Torque | 3322 gf·cm |
| Stall Torque | 21637.2 gf·cm |
| Rated Power | 6426.85 W |
| Max Efficiency | 52.560 % |
| Gearbox Length | 136 mm |
| Gear Ratio | 13 :1 |
| Number Of Gear Stages | 3 |
| Max Continuous Torque | 10 kgf·cm |
| Instantaneous Break Torque | 30 kgf·cm |
| Backlash | 3 ° |
| Operating Temperature Range | -30 ~ 65 C |
| Working Lifespan | 800 hours |
| Noise Level @ 30cm | 53 |
