Model & Selection
Model & Specification Comparison
| SKU | Motor Model | Motor Type | Rated Voltage | No Load Speed | Rated Speed | No Load Current | Rated Current | Stall Current | Rated Torque | Stall Torque | Rated Power | Max Efficiency | Motor Diameter | Motor Length | Motor Weight | Shaft Diameter | Shaft Configuration | Working Lifespan | Operating Temperature Range | Noise Level At 30 cm | Noise Level At 50 cm | Housing Material | Direction Of Rotation | Number Of Pole Pairs | Number Of Phases | Magnet Material | Enameled Wire Material | Insulation Class | Hall Sensor | Motor Control | Gearbox |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 36124500 | BL36-124500 | Brushless DC Motor | 12 V | 4,500 rpm | 3,762 rpm | 200 mA | 690 mA | 4,200 mA | 150 gf·cm | 1,126 gf·cm | 5.80 W | 64 % | 36 mm | 57 mm | 243 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 43 dB | 38 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
| 36126000 | BL36-126000 | Brushless DC Motor | 12 V | 6,000 rpm | 4,931 rpm | 460 mA | 1,900 mA | 8,900 mA | 280 gf·cm | 1,680 gf·cm | 14.20 W | 64 % | 36 mm | 57 mm | 243 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 43 dB | 38 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
| 36184200 | BL36-184200 | Brushless DC Motor | 18 V | 4,200 rpm | 3,500 rpm | 210 mA | 1,130 mA | 6,500 mA | 370 gf·cm | 2,630 gf·cm | 14 W | 78 % | 36 mm | 57 mm | 243 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 44 dB | 39 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
| 36244500 | BL36-244500 | Brushless DC Motor | 24 V | 4,500 rpm | 3,300 rpm | 170 mA | 520 mA | 2,300 mA | 240 gf·cm | 1,267 gf·cm | 8.10 W | 77 % | 36 mm | 57 mm | 237 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 53 dB | 48 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
| 36246000 | BL36-246000 | Brushless DC Motor | 24 V | 6,000 rpm | 5,100 rpm | 260 mA | 1,200 mA | 7,400 mA | 400 gf·cm | 2,825 gf·cm | 21.20 W | 77 % | 36 mm | 57 mm | 237 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 53 dB | 48 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
| 36249000 | BL36-249000 | Brushless DC Motor | 24 V | 9,000 rpm | 7,937 rpm | 470 mA | 2,200 mA | 14,100 mA | 440 gf·cm | 3,400 gf·cm | 35.90 W | 72 % | 36 mm | 57 mm | 243 g | 3.175 mm | Single | 5,000 hours | -30 ~ 65 C | 53 dB | 48 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Cusomized | 3 phase rectangular wave rectified + PWM | PG36 |
Technical Specifications
| Motor Model | BL36-124500 |
|---|---|
| Motor Type | Brushless DC Motor |
| Rated Voltage | 12 V |
| No Load Speed | 4,500 rpm |
| Rated Speed | 3,762 rpm |
| No Load Current | 200 mA |
| Rated Current | 690 mA |
| Stall Current | 4,200 mA |
| Rated Torque | 150 gf·cm |
| Stall Torque | 1,126 gf·cm |
| Rated Power | 5.80 W |
| Max Efficiency | 64 % |
| Motor Diameter | 36 mm |
| Motor Length | 57 mm |
| Motor Weight | 243 g |
| Shaft Diameter | 3.175 mm |
| Shaft Configuration | Single |
| Working Lifespan | 5,000 hours |
| Operating Temperature Range | -30 ~ 65 C |
| Noise Level At 30 cm | 43 dB |
| Noise Level At 50 cm | 38 dB |
| Housing Material | Electrolytic zinc coated steel |
| Direction Of Rotation | Electronically reversible |
| Number Of Pole Pairs | 4 |
| Number Of Phases | 3 |
| Magnet Material | Nd2Fe14B |
| Enameled Wire Material | Enameled Copper Wire |
| Insulation Class | UEW |
| Hall Sensor | Cusomized |
| Motor Control | 3 phase rectangular wave rectified + PWM |
| Gearbox | PG36 |
