Model & Selection
Model & Specification Comparison
| SKU | Motor Model | Motor Type | Rated Voltage | No Load Speed | Rated Speed | No Load Current | Rated Current | Stall Current | Rated Torque | Stall Torque | Rated Power | Max Efficiency | Motor Diameter | Motor Length | Motor Weight | Shaft Diameter | Shaft Configuration | Working Lifespan | Operating Temperature Range | Noise Level At 30 cm | Noise Level At 50 cm | Housing Material | Direction Of Rotation | Number Of Pole Pairs | Number Of Phases | Magnet Material | Enameled Wire Material | Insulation Class | Hall Sensor | Motor Control | Gearbox |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 28126000 | BL28-126000 | Brushless DC Motor | 12 V | 6,000 rpm | 5,300 rpm | 150 mA | 490 mA | 2,620 mA | 78 gf·cm | 497 gf·cm | 4.12 W | 80 % | 27.7 mm | 37.5 mm | 84 g | 2.3 mm | Single | 5,000 hours | -30 ~ 65 C | 48 dB | 43 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Customized | 3 phase rectangular wave rectified + PWM | PG28 |
| 28246000 | BL28-246000 | Brushless DC Motor | 24 V | 6,000 rpm | 5,100 rpm | 100 mA | 300 mA | 4,300 mA | 89 gf·cm | 534 gf·cm | 4.64 W | 71 % | 27.7 mm | 37.5 mm | 84 g | 2.3 mm | Single | 5,000 hours | -30 ~ 65 C | 50 dB | 45 dB | Electrolytic zinc coated steel | Electronically reversible | 4 | 3 | Nd2Fe14B | Enameled Copper Wire | UEW | Customized | 3 phase rectangular wave rectified + PWM | PG28 |
Technical Specifications
| Motor Model | BL28-126000 |
|---|---|
| Motor Type | Brushless DC Motor |
| Rated Voltage | 12 V |
| No Load Speed | 6,000 rpm |
| Rated Speed | 5,300 rpm |
| No Load Current | 150 mA |
| Rated Current | 490 mA |
| Stall Current | 2,620 mA |
| Rated Torque | 78 gf·cm |
| Stall Torque | 497 gf·cm |
| Rated Power | 4.12 W |
| Max Efficiency | 80 % |
| Motor Diameter | 27.7 mm |
| Motor Length | 37.5 mm |
| Motor Weight | 84 g |
| Shaft Diameter | 2.3 mm |
| Shaft Configuration | Single |
| Working Lifespan | 5,000 hours |
| Operating Temperature Range | -30 ~ 65 C |
| Noise Level At 30 cm | 48 dB |
| Noise Level At 50 cm | 43 dB |
| Housing Material | Electrolytic zinc coated steel |
| Direction Of Rotation | Electronically reversible |
| Number Of Pole Pairs | 4 |
| Number Of Phases | 3 |
| Magnet Material | Nd2Fe14B |
| Enameled Wire Material | Enameled Copper Wire |
| Insulation Class | UEW |
| Hall Sensor | Customized |
| Motor Control | 3 phase rectangular wave rectified + PWM |
| Gearbox | PG28 |
